WebSocket Chat Plugin

📋 Overview

The WebSocket Chat plugin enables real-time messaging in your Bubble native mobile apps. This guide will walk you through setting up a basic WebSocket server and connecting it to your Bubble app.

🚀 Quick Start

1 Set Up WebSocket Server

First, let's create a simple WebSocket server. You'll need Node.js installed on your server.

Install Dependencies

mkdir websocket-chat-server
cd websocket-chat-server
npm init -y
npm install express ws

Create Server File

Create a file named server.js:

const express = require('express');
const http = require('http');
const WebSocket = require('ws');

const app = express();
const server = http.createServer(app);
const wss = new WebSocket.Server({ server });

// Store connected clients by room
const rooms = {};

// Store recent messages in memory (simple implementation)
const messageHistory = {};

// Helper: Add client to room
function addToRoom(roomId, ws) {
	if (!rooms[roomId]) {
		rooms[roomId] = new Set();
	}
	rooms[roomId].add(ws);
	console.log(`Client added to room ${roomId}. Total: ${rooms[roomId].size}`);
}

// Helper: Remove client from room
function removeFromRoom(roomId, ws) {
	if (rooms[roomId]) {
		rooms[roomId].delete(ws);
		if (rooms[roomId].size === 0) {
			delete rooms[roomId];
		}
	}
}

// Helper: Broadcast message to room
function broadcastToRoom(roomId, message) {
	if (!rooms[roomId]) return;

	const messageStr = JSON.stringify(message);
	rooms[roomId].forEach(client => {
		if (client.readyState === WebSocket.OPEN) {
			client.send(messageStr);
		}
	});
}

// Helper: Save message to history
function saveMessage(roomId, message) {
	if (!messageHistory[roomId]) {
		messageHistory[roomId] = [];
	}

	messageHistory[roomId].push(message);

	// Keep only last 100 messages
	if (messageHistory[roomId].length > 100) {
		messageHistory[roomId].shift();
	}
}

// Helper: Get message history
function getHistory(roomId, limit = 50) {
	if (!messageHistory[roomId]) return [];

	const history = messageHistory[roomId];
	const start = Math.max(0, history.length - limit);
	return history.slice(start);
}

// WebSocket connection handler
wss.on('connection', (ws) => {
	console.log('New client connected');
	let currentRoom = null;

	ws.on('message', (data) => {
		try {
			const message = JSON.parse(data);
			console.log('Received:', message);

			// Handle get_history request
			if (message.action === 'get_history') {
				currentRoom = message.room;
				addToRoom(currentRoom, ws);

				const history = getHistory(currentRoom, message.limit || 50);

				ws.send(JSON.stringify({
					type: 'history',
					messages: history
				}));
			}

			// Handle send_message request
			else if (message.action === 'send_message') {
				const roomId = message.room;

				const messageData = {
					id: Date.now().toString() + Math.random(),
					text: message.text,
					sender: message.sender,
					sender_id: message.user_id,
					timestamp: message.timestamp || new Date().toISOString()
				};

				// Save to history
				saveMessage(roomId, messageData);

				// Broadcast to all clients in room
				broadcastToRoom(roomId, {
					type: 'message',
					...messageData
				});

				console.log(`Message sent to room ${roomId}`);
			}

		} catch (error) {
			console.error('Error:', error);
		}
	});

	ws.on('close', () => {
		if (currentRoom) {
			removeFromRoom(currentRoom, ws);
		}
		console.log('Client disconnected');
	});
});

// HTTP endpoint for sending messages via API
app.use(express.json());

app.post('/api/send-message', (req, res) => {
	try {
		const { user_id, room, text, sender, timestamp } = req.body;

		if (!user_id || !room || !text) {
			return res.status(400).json({
				success: false,
				error: 'Missing required fields: user_id, room, text'
			});
		}

		const messageData = {
			id: Date.now().toString() + Math.random(),
			text: text,
			sender: sender || 'User',
			sender_id: user_id,
			timestamp: timestamp || new Date().toISOString()
		};

		// Save to history
		saveMessage(room, messageData);

		// Broadcast to WebSocket clients
		broadcastToRoom(room, {
			type: 'message',
			...messageData
		});

		res.json({ success: true, message_id: messageData.id });

	} catch (error) {
		res.status(500).json({ success: false, error: error.message });
	}
});

// Health check endpoint
app.get('/health', (req, res) => {
	res.json({ status: 'ok', connections: wss.clients.size });
});

// Start server
const PORT = process.env.PORT || 8080;
server.listen(PORT, () => {
	console.log('========================================');
	console.log(`WebSocket Server running on port ${PORT}`);
	console.log(`WebSocket: ws://localhost:${PORT}`);
	console.log(`HTTP API: http://localhost:${PORT}/api/send-message`);
	console.log('========================================');
});

Run the Server

node server.js

2 Configure Bubble Plugin

In your Bubble app, add the WebSocket Chat element and configure these properties:

3 Add Message Input

Create the UI for sending messages:

1. Add a Text Input element
2. Add a Button labeled "Send"
3. Create a workflow on the button click:
   • Action: Plugins → WebSocket Chat → Send Message
   • Element: Your chat element
   • message_text: Input's value
4. Add another action to clear the input

📡 Message Protocol

Messages Plugin Sends to Server

{
  "action": "get_history",
  "user_id": "user123",
  "room": "room456",
  "limit": 50
}

{
  "action": "send_message",
  "text": "Hello, this is my message",
  "user_id": "user123",
  "sender": "John Doe",
  "room": "room456",
  "timestamp": "2026-01-11T22:38:04.014Z"
}

Messages Server Sends to Plugin

{
  "type": "history",
  "messages": [
	{
	  "id": "msg_001",
	  "text": "Hello!",
	  "sender": "Jane Smith",
	  "sender_id": "user789",
	  "timestamp": "2026-01-11T20:15:00.000Z"
	}
  ]
}

{
  "type": "message",
  "id": "msg_003",
  "text": "New message here",
  "sender": "Jane Smith",
  "sender_id": "user789",
  "timestamp": "2026-01-11T22:38:04.014Z"
}

🔧 Sending Messages via HTTP API

You can send messages to the chat from your backend using the HTTP endpoint:

Using cURL

curl -X POST http://your-domain.com:8080/api/send-message \
  -H "Content-Type: application/json" \
  -d '{
	"user_id": "user123",
	"room": "room456",
	"text": "Hello from the server!",
	"sender": "Admin"
  }'

Using JavaScript

fetch('http://your-domain.com:8080/api/send-message', {
  method: 'POST',
  headers: {
	'Content-Type': 'application/json'
  },
  body: JSON.stringify({
	user_id: 'user123',
	room: 'room456',
	text: 'Hello from JavaScript!',
	sender: 'System'
  })
})
.then(response => response.json())
.then(data => console.log('Success:', data));

Using PHP

<?php
$url = 'http://your-domain.com:8080/api/send-message';

$data = array(
	'user_id' => 'user123',
	'room' => 'room456',
	'text' => 'Hello from PHP!',
	'sender' => 'Backend'
);

$ch = curl_init($url);
curl_setopt($ch, CURLOPT_RETURNTRANSFER, true);
curl_setopt($ch, CURLOPT_POST, true);
curl_setopt($ch, CURLOPT_POSTFIELDS, json_encode($data));
curl_setopt($ch, CURLOPT_HTTPHEADER, array('Content-Type: application/json'));

$result = curl_exec($ch);
curl_close($ch);

echo $result;
?>

🎨 Customization Options

Display Options

• reverse_message_order: Show newest messages at top (yes) or bottom (no)
• show_built_in_ui: Use plugin's UI (yes) or build your own (no)
• show_status_bar: Display connection status

Styling Properties

Customize colors, sizes, and appearance:

• my_message_color - Background for your messages
• other_message_color - Background for other messages
• message_border_radius - Rounded corners
• container_background_color - Chat background
• And many more text colors and sizes!

🚢 Production Deployment

Using SSL (wss://)

To use secure WebSocket connections, modify your server:

const https = require('https');
const fs = require('fs');

const SSL_OPTIONS = {
  key: fs.readFileSync('/path/to/your/ssl.key'),
  cert: fs.readFileSync('/path/to/your/ssl.crt')
};

const server = https.createServer(SSL_OPTIONS, app);
// Then use wss://your-domain.com:8080

🔍 Troubleshooting

Can't Connect to Server

• Check if server is running: curl http://your-domain.com:8080/health
• Verify firewall allows connections on port 8080
• Use ws:// for testing (not wss://)

Messages Not Appearing

• Check server logs for errors
• Verify room_id matches between users
• Ensure all required fields are present in messages

"My" Messages on Wrong Side

• Ensure sender_id exactly matches current_user_id
• Both must be strings and match character-for-character
